PVDF combines near-PTFE chemical resistance with far better machinability and stiffness — which is why semiconductor wet-process equipment and chemical analytical systems are full of PVDF parts. High purity matters too: PVDF is one of the few polymers accepted in ultra-clean fluid paths.
Parts for wet processing and chemical handling, machined without contamination-introducing practices.
Unlike PTFE, PVDF is rigid — real tolerances on real geometry, ±0.01 mm standard.
Cleanroom and ESD-safe packaging options for semiconductor and analytical applications.
Real capability windows — verified in-house, not estimated.
| Capability | Specification |
|---|---|
| Material | PVDF (Kynar-class fluoropolymer) |
| Typical tolerance | ±0.01 mm standard; tighter where geometry allows |
| Chemical resistance | Excellent — acids, halogens, most solvents |
| Temperature capability | Continuous service up to ~150 °C |
| Processes | CNC milling, turning, Swiss-type |
| Packaging | Cleanroom / ESD-safe options |
| Prototype lead time | Typically 5–10 working days |
A transparent, engineering-led process built for long-term supply programs — not one-off transactions.
Send drawings and program context. Our engineers run a DFM review and flag tolerances, materials and risk before any cutting begins.
You receive a transparent quote plus a material-verification plan — grade, EN/DIN check and certificate strategy for your application.
In-house precision machining, then Zeiss CMM dimensional inspection and spectrometer material verification on critical batches.
Kitted, ESD-safe or cleanroom packaging, with local engineering and after-sales support through our German partner.
Tell us about your program. The fields below help our engineering team prioritize recurring, long-term supply programs with equipment manufacturers.
Every critical dimension is verified on our in-house Zeiss CMM · material chemistry confirmed by spectrometer · EN 10204 3.1 certificates available.
